Flat Crystal
Plane optical flats are used to inspect the flatness and planarity of gauge blocks, as well as the flatness of the measuring surfaces and working surfaces of instruments and tools.
Description
The flat optical flat is used to inspect the wrring quality and flatness of gauge blocks, as well as the flatness of measuring surfaces and working surfaces of instruments and tools.
It can also be used to inspect high-precision flat components, such as flat optical elements, high-grade platforms, plates, guide rails, sealing parts, etc.
The flat optical flat is particularly suitable for metrology institutions and laboratories as a standard reference plane and template.
Precautions:
If the desired style is not available in the standard product list, you may contact sales for customization.
What services can Elyonoptic provide?
- Small batch products are numbered,and each product of provider the ZYGO surface data,Diameter data,Center thickenss data,Total height data,center bias data
- Large-scale products provide five-thousandths of product data
- Provide the proof of product material
- Coating products provide coating curve
How long is Elyonoptic delivery date?
10-300pcs:15-25days
1000-5000pcs:35days
5000-10000pcs:45days
(Specific delivery date suggestions and sales verification)
We deliver bulk products in batches
FAQs
1. What is your MOQ for flat crystal?
Our standard MOQ is 50 pieces for regular production.
For small orders (≤50 pcs), we can still accept production and provide full inspection reports and measurement data for each piece upon request.
2. Do you support small batch or prototype orders?
Yes. We support small batch and prototype production for testing and evaluation before mass production.
3. What is your production lead time?
- Standard products: 4–5 weeks
- Coated optical windows (AR / HR): 5–6 weeks, depending on coating type and specifications
4. Do you provide inspection reports?
Yes. We provide quality inspection reports based on order quantity:
- ≤50 pcs: Full inspection data for each piece available
- 100–1,000 pcs: 5%–10% random sampling inspection reports
- >1,000 pcs: 0.5% sampling inspection reports
All inspection data includes dimensional and surface quality parameters.
5. What coating options are available?
We offer:
- Anti-Reflection (AR) coatings
- High-Reflection (HR) coatings
- Broadband coatings
- Custom wavelength coatings (UV / Visible / IR)
6. Can you manufacture custom sizes and shapes?
Yes. We support OEM manufacturing according to drawings.
Available shapes include:
- Round
- Square
- Rectangular
- Stepped
- Wedged
- Drilled / special structures
7. What quality certifications do you have?
We are certified under international quality management systems, including:
- ISO 9001 Quality Management System
- IATF 16949 Automotive Quality System
- Good Standardization Practices Certification
We also apply strict internal quality control processes, including dimensional inspection, surface quality testing, and coating performance verification before shipment.
